QTech 5 Stage HVLP Turbine – Suction

It’s all about the detail with the clever QTech 5 Stage HVLP Turbine – Suction paint spray machine. Created with the professional decorator in mind, these compact, lightweight and portable paint sprayers makes painting details quick and easy. The QTech 5 Stage HVLP Turbine – Suction is part of an all-new range of turbines combining the cost-effectiveness of the QTech brand with the best in manufacturing from North America.This HVLP is suited to trim and fine finish spraying including:

• Balustrades
• Spindles
• Panelled doors
• Skirting
• Architrave
• Cabinets
• Bath enamels
• Pianos
• Bespoke Furniture

Use to Spray

Compatible with water and solvent based primers, undercoats and top coats, most would need to be thinned dependant on viscosity.
Ideal coatings include:

• gloss and wood primers
• cellulose coatings
• Lacquers
• Varnish
• Stains
• solvent based top coats
• wood preservatives
• other coatings with a good ‘flow’.

FEATURES

• Stainless steel needle/nozzle 0.8 mm – 2.5 mm with a 1.5mm needle/nozzle as standard fitment
• Fan size fully adjustable from one control on side of gun – select from circle to wide pattern or anywhere in-between
• Non-bleed spray gun – air only passes through the gun when the trigger is pulled
• Quick change filters
• 2-year warranty on parts and labour

Usage Frequency

• Most of the week

Specification

• MWP 0.66 bar | 9.5 psi
• Motor 1600 watt
• Weight 14.80 kg
• Cup 1 ltr
• Power supply 110 / 240 volt

Supplied Complete With

• QTech Q70 HVLP suction gun
• 1.5mm needle/nozzle
• 7.5m hose assembly + 2m whip
• Viscosity cup
• Wrench | Wet film gauge
• 19pc cleaning & maintenance kit

Warranty

For two years from date of purchase QTech HVLP Turbines are warranted under normal use and service against all manufacturing defects. The replacement of any and all wearing parts is not covered by this warranty. Where servicing has not been carried out at the recommended intervals this could invalidate the warranty.

HVLP 5 Machine Setup:
